Newlong Industrial DR-7UW (For making FIBC Bags) DRU7W

Newlong Industrial (NLI) DR-7UW Two Needle, Plain Feed with Upper Feed, Flat Bed, Four Thread Chain Stitch Machine Used for Sewing Very Thick Materials such as Polypropylene  Container Bags, Big Bag, FIBC (Flexible Intermediate Bulk Container)

Maquina de Dos Agujas, Alimentacion Sencilla y Superior, Cama Plana, Cadeneta de Cuatro Hilos para coser material muy gruesos com Big Bag (Jumbo Bags) de Polipropileno.

Technical Specifications for Newlong DR-7uW / Caracteristicas Tecnicas para Newlong DR7uw

Model Newlong dr7uw Newlong DR-7UW
Max. Speed ※ 1,400rpm
Seam Double thread chain stitch (Type 401)
Stitch Width 7-12mm
Bag Material Container bag
Thickness 18mm
Cutter
Needle UO-H33 #29
Oiling by hand ・ Oiler
Oil Machine oil #10
weight 45.0kg
Feature Upper & Lower sending ・ Double needle
Related Machines TR-7UW、Table setting

※ depending on sewing material and operation


Brand: Newlong Industrial Co., Ltd.
Made in Japan

Need the manual of the DR-7UW? contact us.

Newlong DRu7W
Newlong DR-U7W
